∅D1 |
∅d1 |
∅d2 |
∅d3 |
L1+0.25-0 |
L2 0-0.15 |
PART NO. |
|
100 |
75 |
93.24 |
98.0 |
22.0 |
6.45 |
0034950 |
|
100 |
75 |
93.85 |
98.0 |
26.0 |
9.50 |
0891650 |
|
100 |
80 |
93.85 |
98.0 |
31.0 |
7.00 |
0295150 |
|
110 |
85 |
103.5 |
108.0 |
22.0 |
6.45 |
1188250 |
|
110 |
90 |
103.85 |
108.0 |
31.0 |
7.00 |
0712450 |
|
115 |
95 |
108.85 |
113.0 |
31.0 |
7.00 |
0796450 |
|
120 |
100 |
113.85 |
118.0 |
31.0 |
7.00 |
0296150 |
|
125 |
100 |
118.50 |
123.00 |
25.00 |
6.45 |
1007450 |
|
125 |
100 |
118.85 |
123.00 |
38.00 |
9.50 |
0418650 |
|
130 |
104 |
123.85 |
128.00 |
38.00 |
9.50 |
0244350 |
|
130 |
105 |
123.50 |
128.00 |
25.00 |
6.45 |
0044850 |
|
135 |
110 |
128.35 |
133.00 |
38.00 |
9.50 |
0304350 |
|
140 |
115 |
133.50 |
138.00 |
25.00 |
6.45 |
1008450 |
|
140 |
120 |
133.85 |
138.00 |
31.00 |
7.00 |
0250550 |
|
145 |
125 |
138.85 |
143.00 |
31.00 |
7.00 |
0640150 |
|
150 |
120 |
143.85 |
148.00 |
44.00 |
9.50 |
1289550 |
|
150 |
125 |
143.50 |
148.00 |
25.00 |
6.45 |
1008050 |
|
160 |
130 |
153.50 |
158.00 |
25.00 |
6.45 |
1008250 |
|
160 |
135 |
153.85 |
158.00 |
38.00 |
9.50 |
0080450 |
|
160 |
140 |
153.85 |
158.00 |
31.00 |
7.00 |
0304650 |
|
170 |
140 |
162.54 |
168.00 |
25.00 |
6.45 |
1222250 |
|
170 |
150 |
163.85 |
168.00 |
31.00 |
7.00 |
0303350 |
|
180 |
150 |
173.00 |
178.00 |
35.00 |
6.45 |
0679850 |
|
180 |
160 |
173.85 |
178.00 |
31.00 |
7.00 |
1283150 |
|
190 |
160 |
183.85 |
188.00 |
44.00 |
9.50 |
0838450 |
|
200 |
170 |
193.85 |
198.00 |
44.00 |
12.00 |
0087150 |
|
200 |
175 |
193.85 |
198.00 |
38.00 |
9.50 |
0838850 |
|
210 |
180 |
203.13 |
208.00 |
31.70 |
6.45 |
1198450 |
|
220 |
200 |
213.85 |
218.00 |
31.00 |
7.00 |
1056450 |
|
250 |
220 |
243.85 |
248.00 |
44.00 |
12.00 |
1056350 |
|
280 |
250 |
273.85 |
278.00 |
44.00 |
12.00 |
1055550 | |
|
|
